Allen Bradley 1769-IF16C
The Allen-Bradley 1769-IF16C is a Compact I,O high-density analog input module with Sixteen (16) single-ended input channels. This module is designed to accept 0-20 mA and 4-20 mA input signals with resolution of 16 bits (unipolar) and 15 bits plus sign (bipolar). This module is compatible for use with a 1769 CompactLogix chassis or MicroLogix 1500 controller.
This Allen Bradley 1769-IF16C is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input > Compactlogix range and is referenced internally as PartLogic SKU PL26805542711.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Analog Input Module |
| Product Line | CompactLogix |
| Part Number | 1769-IF16C |
| UPC | 612598626786 |
| Weight | 0.50 lbs (0.23 kg) |
| No. of Inputs | 16 Single Ended Inputs |
| Power Supply Distance rating | 8 |
| Input current range | 0-21 mA |
| Current signal normal ranges | 0-20mA; 4-20 mA |
| Current signal full range | 0-21 mA; 3.2 - 21 mA |
| Compatible Controllers | MicroLogix 1500; CompactLogix |
| Resolution | 16 bits (unipolar) 15 bits plus sign (bipolar) |
| Channel Diagnostics | Over- or under-range by bit reporting, process alarms |
| Slot width | 1 |
| Recommended cable | Belden™ 8761 (shielded) |
| Module Type | 16 Point Analog Current Input Module |
| Input Type | Analog Input |
| Communication Cable | 16 Point |
| Series | A and B |
| Enclosure Type | Open |
| Backplane Current | 1.4 Amps at 24 Volts |
| Power Consumption | 33.6 Watts |
| Power Dissipation | 7.5 Watts |
| Isolation Voltage | 30 Volts DC |
| Brand | Allen Bradley |
