Allen Bradley 1764-28BXB
The 1764-28BXB is a MicroLogix 1500 base unit that belongs to the Bulletin 1764 product family. It has a line power voltage requirement of 20.4 to 30VDC, integrated Eight (8) Standard 24VDC sink,source discrete inputs, Eight (8) High-Speed inputs and Six (6) Relay Outputs, Four (4) Standard 24VDC outputs and Two (2) Fast 24VDc outputs. It has integrated RS232 communication ports for device communication.
This Allen Bradley 1764-28BXB is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Micrologix > 1500 range and is referenced internally as PartLogic SKU PL26805304358.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | MicroLogix 1500 |
| Part Number | 1764-28BXB |
| GTIN | 10611320023623 |
| Weight | 1.63 lbs (0.74 kg) |
| Function | Base Controller |
| I/O Count | 16 inputs/12 outputs |
| Module Type | Base Unit |
| Max Expanded I/O Count | 512 |
| No. of Inputs | 16 inputs |
| Input Voltage | 24 Volts DC |
| Input channel Voltage | 24V dc, sink/source |
| Output Source | Relay Port and DC FET |
| High Speed Input Frequency | Eight (8) 20 kHz input |
| No. of Outputs | Six (6) Relay; Four (4) Standard 24VDC Transistor; Two (2) Fast 24VDC |
| Input Circuit Type | 24 Volt DC Sink/Source |
| Relay Output channel Voltage | 24-125VDC; 120-240VAC |
| Output Circuit Type | 6 Relay, 6 FET Transistor |
| Transistor Output channel Voltage | 20.4VDC - 26.4VDC |
| Line Power | 20.4-30.0 Volts DC |
| High Speed Output Frequency | 20 kHz output |
| Power Supply Usage | 30 Watts |
| Power Supply Voltage | 20.4 to 30VDC |
| Power Supply Inrush Current | 24V dc = 4A for 150 ms |
| Maximum Load Current | 400 mA |
| Mounting | Horizontal |
| Compatible Processors | 1764-LSP and 1764-LRP |
| Product Lifecycle Status* | Discontinued/Obsolete |
| Brand | Allen Bradley |
