Allen Bradley 1762-OW8
The Allen-Bradley 1762-OW8 output module is a solid-state type of industrial output module. It is part of the Allen-Bradley MicroLogix 1200 series and it can be used as part of a MicroLogix control system. The 1762-OW8 output module can be mounted on a DIN Rail and it is meant to be used in clean and dry industrial environments that have Pollution Degree 2 pollution ratings. This solid-state output module needs to be protected from ESD or electrostatic discharge at all times during storage, installation, operation, and maintenance. The 1762-OW8 solid-state output module has 8 output channels and it can operate at 32 to 131 degrees Fahrenheit.
This Allen Bradley 1762-OW8 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Micrologix range and is referenced internally as PartLogic SKU PL26805590380.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Model number | 1762-OW8 |
| Output type | Relay, AC/DC |
| Number of outputs | 8 points |
| Isolation groups | Group 1: 0–3, Group 2: 4–7 |
| I/O status indication | LED |
| Connection type | Screw connection |
| Signal delay | On 10 ms, Off 10 ms (resistive) |
| Continuous current per point, max | 2.5 A |
| Continuous current per common, max | 8 A |
| Continuous current per module, max | 16 A |
| Bus current draw, max | 90 mA @ 24 VDC (2.16 W) |
| Heat dissipation, max | 2.9 W |
| Operating temperature | -20 to 65 °C |
| Storage temperature | -40 °C |
| Operating humidity | 5–95% noncondensing |
| Altitude | 2000 m |
| ESD immunity IEC 1000-4-2 | 4 kV contact, 8 kV air, 4 kV indirect |
| EFT/B immunity IEC 1000-4-4 | 2 kV @ 5 kHz |
| Surge immunity IEC 1000-4-5 | 2 kV common, 1 kV differential |
| Conducted RF immunity IEC 1000-4-6 | 10 V @ 0.15–80 MHz |
| Radiated RF immunity IEC 1000-4-3 | 10 V/m, 80–1000 MHz |
| Emissions EN 50081-2 | Class A |
| Shock | Operating 30 G panel mounted, 3 pulses/axis; relay ops 7 G |
| Vibration | Operating 10–500 Hz, 5 G, 0.030 in p‑p; relay ops 1.5 G |
| Power supply distance rating | 6 modules from power supply |
| Type of electric connection | Screw terminal |
| Dimensions (H x D x W) | 90 mm x 87 mm x 40.4 mm |
| Weight | 228 g |
| Off-state leakage current, max | 0 mA |
