Allen Bradley 1762-IT4
The Allen-Bradley 1762-IT4 is a MicroLogix 1200 analog input module. This module is a Thermocouple and millivolt input module that features Four (4) channels plus CJC sensor compatible with Thermocouple sensors J, K, T, E,R, N, S, B, and C. and accepts +,- 50mV and +,-100mv signals. It has 15 bit resolution (plus sign) utilizing Sigma-Delta conversion method. It comes with selectable input filtering and channel update time.
This Allen Bradley 1762-IT4 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input > Micrologix range and is referenced internally as PartLogic SKU PL26801443315.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| 4 | Compatible Controllers: |
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | MicroLogix 1200 |
| Part Number | 1762-IT4 |
| UPC | 611320861662 |
| Weight | 0.25 lbs (0.11 kg) |
| Converter Type | Delta-Sigma |
| Product Description | Thermocouple input module |
| Number of Inputs | Four (4) |
| Compatible Thermocouple sensors | Type J, Type K, Type T, Type E, Type R, Type S, Type B, Type N, and Type C |
| Compatible millivolt signals | -50…50 mV and -100…100 mV |
| Module resolution | 15-bits |
| Filter frequency | 10 Hz; 50 Hz; 60 Hz; 250 Hz; 500 Hz; 1 kHz |
| Channel update time | 303 ms; 63 ms; 53 ms; 15 ms; 9 ms; 7 ms |
| Enclosure | Open-type |
| Mounting | DIN Rail |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Module Type | Thermocouple/mV Input |
| 1762- IT4 | Product Family: |
| Inputs | 4 Channels plus 1 CJC Sensor |
| MicroLogix 1200 | Product Type: |
| Input Filtering | Programmable Notch Filter |
| Thermocouple / milivolt Input Module | No. of Inputs: |
| Calibration | Autocalibrates |
| Power Supply Distance Rating | 6 |
| J, K, T, E, R, N, S, B, N, C | millivolt signal: |
| Heat Dissipation | 1.5 Total Watts |
| +/- 50mV and +/-100mV | CJC sensor: |
| Included | Module Resolution |
| 15-bits plus sign | Converter type |
| Delta-Sigma | Current draw @ 5.1V: |
| 40 mA | Current draw @ 24V: |
| 50 mA | Heat dissipation, max: |
| 1.5W | Calibration: |
| Performed during power-up; programmable | CJC sensor accuracy: |
| Brand | Allen Bradley |
