Allen Bradley 1762-IF4
The 1762-IF4 is a compact Four (4) Differential channels analog input module. This module supports 4-20 mA and -10 to 10V DC signals. This module is compatible for MicroLogix 1100, 1200 and 1400 Programmable Logic Controllers.
This Allen Bradley 1762-IF4 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input > Micrologix range and is referenced internally as PartLogic SKU PL26801461665.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Model | 1762-IF4 |
| Inputs | 4 differential (bipolar) analog inputs |
| Signal types | ±10 V DC, 4–20 mA |
| Resolution | 15 bit |
| ADC type | Successive approximation |
| Input update time | 130, 250, 290, 450, 530 ms selectable |
| Full scale ranges | Voltage: −10.5…10.5 V DC; Current: −21…21 mA |
| Normal operating voltage range | −10…10 V DC |
| Repeatability | −0.12 to 0.12% |
| Common-mode voltage range | −27 to 27 V |
| Common-mode rejection | >55 dB at 50/60 Hz |
| Input impedance (voltage) | 200 kΩ |
| Protection | Current input −32 mA; Voltage input −30 V |
| Diagnostics | Over/under range or open circuit bit reporting |
| I/O isolation | Isolated |
| Status indication | LED; Power LED indicates power applied |
| Electrical connection | Screw connection |
| Bus current draw (max) | 40 mA @ 5 V DC; 50 mA @ 24 V DC |
| Operating temperature | −20 to 65 °C |
| Storage temperature | −40 °C minimum |
| Operating humidity | 5…95% noncondensing |
| Operating altitude | 2000 m |
| ESD immunity | EN 61000-4-2, 4 kV contact, 8 kV air, 4 kV indirect |
| Radiated immunity | 10 V/m, 80…1000 MHz, 80% AM, +900 MHz keyed carrier |
| Conducted immunity | 10 V, 0.15…80 MHz |
| Fast transient burst | 2 kV @ 5 kHz |
| Surge immunity | 1 kV galvanic gun |
| Isolation test | 500 V AC or 707 V DC for 1 min |
| Width | 40 mm |
| Height | 90 mm |
| Depth | 87 mm |
| Shipping weight | 240 g (0.53 lb) approximately |
| Mounting | DIN rail or panel |
| Enclosure rating | IP20 |
| Recommended cable | Belden 8761 (shielded) |
