Allen Bradley 1756-OX8I
The 1756-OX8I is a ControlLogix Discrete output module which operate at a voltage category of 5 to 125VDC and 10 - 240 VAC. This module has Eight (8) Normally Open (N.O) and Eight (8) Normally Closed (N.C) contact outputs. This module is directly installed to a 1756 local or remote chassis.
This Allen Bradley 1756-OX8I is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Controllogix range and is referenced internally as PartLogic SKU PL26805306996.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | ControlLogix |
| Part Number | 1756-OX8I |
| UPC | 612598171477 |
| Weight | 0.88 lbs (0.40 kg) |
| Outputs | 8-Point Individually Isolated |
| Module Type | Isolated Relay Output Module |
| Output Current | 2, 0.5, 0.25 Amps |
| Contact Output | Form C contacts |
| Operating Voltage | 10-265 Volts AC, 5-150 Volts DC |
| Initial Contact Resistance | 100 m? @ 6V 1 A |
| Maximum Switching frequency | 1 operation/3 s (0.3 Hz at rated load) |
| Mean Bounce Time | 1.2 ms |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
| Maximum Output Delay Time | 13 milliseconds |
| Expected contact life | 300 kHz resistive; 100 kHz inductive |
| Backplane Current at 5 Volts | 100 mA |
| Power Dissipation (Max) | 3.1 Watts at 60 Celsius |
| UNSPSC | 32151705 |
| Enclosure | None |
| Isolation Voltage | 250V (continuous), basic insulation type, outputs-to- backplane, and output-to-output |
| Brand | Allen Bradley |
