Allen Bradley 1756-OW16I
The Allen-Bradley 1756-OW16I is a ControlLogix Discrete output module that features Sixteen (16) Normally Open (N.O.), individually isolated contact outputs. Each contact output has a operating voltage range of 5-125VDC and 10-240VAC. It delivers output current ratings of 1 A @ 5-30VDC; 0.5 A @ 48VDC; 0.22 A @ 125VDC; 1.5 A @ 120VAC, 50,60 Hz and 0.75 A @ 240VAC, 50,60 Hz.
This Allen Bradley 1756-OW16I is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Controllogix range and is referenced internally as PartLogic SKU PL26801476449.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | ControlLogix |
| Part Number | 1756-OW16I |
| GTIN | 10612598171467 |
| Weight | 1.00 lbs (0.45 kg) |
| Module Type | Digital DC Sourcing Output |
| No. of outputs | Sixteen (16), individually isolated channels |
| Contact form | Normally Open (N.O.) |
| Operating Voltage range | 5…125V DC; 10…240V AC |
| Output Voltage range | 1 A @ 5…30V DC; 0.5 A @ 48V DC; 0.22 A @ 125V DC; 1.5 A @ 120V AC 50/60 Hz; 0.75 A @ 240V AC 50/60 Hz |
| Current draw @ 5.1V | 150 mA |
| Total backplane Power | 4.4 W |
| Backplane Current, 24VDC | 2 mA |
| Power Dissipation | 4.5 W @ 60 °C (140 °F) |
| Output Signal delay, OFF to ON | 10 ms, max |
| Output Signal delay, ON to OFF | 10 ms max |
| Enclosure type rating | None (open-style) |
| Removable Terminal Block | 1756-TBCH; 1756-TBS6H |
| Outputs | 16-Point Individually Isolated |
| Operating Voltage | 10-265 Volts AC, 5-150 Volts DC |
| Output Current | 2, 0.5, 0.25 Amps |
| Maximum Output Delay Time | 10 milliseconds |
| Contact Output | 13 N.O. |
| Power Dissipation (Max) | 4.5 Watts at 60 Celsius |
| Backplane Current at 5 Volts | 150 milliamps |
| Backplane Current at 24 Volts | 150 milliamps |
| Removeable Terminal Block(s) | 1756-TBCH, 1756-TBS6H |
| Isolation Voltage | 50 Volts Continuous |
| Enclosure | None |
| UPC | 10612598171467 |
| Brand | Allen Bradley |
