Allen Bradley 1756-L72
The 1756-L72 is a controller module for the ControlLogix Modular Programmable Automation Controller (PAC) by Allen-Bradley. It comes with Memory of 4MB, and built-in USB communication interface. It is capable of 128,000 Discrete I,O and 4000 Analog I,O memory with an allocated I,O memory of 0.98 MB.
This Allen Bradley 1756-L72 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Cpu > Controllogix range and is referenced internally as PartLogic SKU PL26801466627.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | ControlLogix |
| Part Number | 1756-L72 |
| UPC | 612598876020 |
| Weight | 0.56 lbs (0.26 kg) |
| I-O Memory | 0.98 MB |
| Module Type | Processor Module |
| User Memory | 4 MB |
| Nonvolatile Memory | 1 GB (1784-SD1 ships with every controller) 2 GB (1784-SD2) |
| Maximum I-O | 128,000 |
| Communication | 1 port USB |
| USB Port Communication | Programming, configuration, and on-line edits |
| Maximum Analog I-O | 4,000 |
| Maximum Digital I-O | 128,000 |
| Current Draw (1.2 Volts DC) | 5 milliamps |
| Current Draw (5.1 Volts) | 800 milliamps |
| Power Dissipation | 2.5 Watts |
| Backplane Current (1.2 Volts DC) | 5 mA |
| Thermal Dissipation | 8.5 BTU per hour |
| Backplane Current (5.1 Volts DC) | 800 mA |
| Isolation Voltage | 30 Volts Continuous |
| Enclosure | None |
| Relative Humidity | 5-95 percent |
| Operating shock | 30G |
| Redundancy | Full Support |
| UNSPSC | 32151705 |
| Programming Languages | Relay ladder Structured text Function block SFC |
| Brand | Allen Bradley |
