Allen Bradley 1746-OA16
The Allen-Bradley 1746-OA16 is an SLC500 Discrete AC output module. This AC output module features Sixteen (16) AC output channels in Two (2) groups of Eight (8) outputs each channel, providing signal voltages of 120,240VAC with output voltage range of 85-265VAC.
This Allen Bradley 1746-OA16 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Slc 500 range and is referenced internally as PartLogic SKU PL26801431848.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | SLC 500 |
| Part Number | 1746-OA16 |
| UPC | 662468067065 |
| Weight | 1.00 lbs (0.45 kg) |
| Module Type | Digital AC Output Module |
| No. of Outputs | Sixteen (16) outputs |
| Output Voltage | 120/240 VAC output |
| Operating Voltage Range | 85-264 VAC |
| Output Delay Time, OFF to ON | 11.0 ms |
| Output Delay Time, ON to OFF | 1 ms |
| OFF state leakage current | 2 mA |
| Load Current | 10 mA |
| Backplane Current at 5.1 Volts | 0.370 A |
| Continuous current per point | 0.50 A @ 30 °C (86 °F) 0.25 A @ 55 °C (131 °F) |
| Continuous current per module, max | 8.0 A @ 30 °C (86 °F) 4.0 A @ 60 °C (140 °F) |
| Voltage Range | 85 to 265 Volts AC |
| Outputs | 16 |
| Current/Output at 30 degrees Celsius | 0.5 Amps |
| Current/Output at 60 degrees Celsius | 0.25 Amps |
| Backplane Current (5 Volts DC) | 370 milliamps |
| Current/Module (30 degrees Celsius) | 8 Amps |
| Applications | General Purpose |
| Step Response | 60 milliseconds in, 2.5 milliseconds out |
| Ambient Operating Temperature | 32 to 140 degrees Fahrenheit |
| UNSPSC | 32151705 |
| Brand | Allen Bradley |
