Allen Bradley 1746-NR4
The Allen-Bradley 1746-NR4 is a SLC 500 RTD,Resistance Analog Input Module. This RTD,Resistance Analog Input Module has Four (4) channels which are compatible for RTD sensors such as Platinum (385), Platinum (3916), Copper (416), Nickel (618), Nickel (672), and Nickel Iron. It is also compatible for direct inputs of resistance devices. This module is compatible for Fixed style and modular style SLC 500.
This Allen Bradley 1746-NR4 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input > Slc 500 range and is referenced internally as PartLogic SKU PL26805308081.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | SLC 500 |
| Part Number | 1746-NR4 |
| GTIN | 10662468165911 |
| Weight | 0.56 lbs (0.26 kg) |
| Inputs | 4 |
| Module Type | RTD/Resistance Analog Input Module |
| No. if Inputs | Four (4) |
| Bandwidth | 2.62-65.5 Hertz |
| Compatible RTD Sensors | Platinum (385) 100, 200, 500 and 1000; Platinum (3816) 100, 200, 500 and 1000; Copper (426) 10, Nickel (618) 120, Nickel (672) 120, and Nickel Iron (518) 604. |
| Update Time | 17 milliseconds-1.2 seconds |
| Compatible Resistance input range | 0 - 150 Ohms, 0 to 500 Ohms, 0 to 1000 Ohms and 0 to 300 Ohms |
| Backplane Current | 50 mA |
| Backplane Power Consumption | 1.5 W max (0.3 W at 5V dc, 1.2 W at 24V dc) |
| I/O Chassis location | Any slot except Slot 0 |
| Step Response | 60 milliseconds in, 2.5 milliseconds out |
| Resolution | .01 Deg. Celcius |
| Operating Isolation | 500 Volts/1 minute |
| Operating Temperature | 0 to 60 degrees Celsius |
| UPC | 10662468440742 |
| Storage Temperature | -40 to 85 degrees Celsius |
| A/D Conversion method | Sigma-delta modulation |
| Brand | Allen Bradley |
