Allen Bradley 1746-NI8
The Allen-Bradley 1746-NI8 is a SLC 500 Analog I,O Module. This Analog I,O Module has Eight (8) non-isolated differential, voltage or current selectable input channels. This module occupies single slot of the SLC 500 chassis and compatible with fixed or modular style hardware.
This Allen Bradley 1746-NI8 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input > Slc 500 range and is referenced internally as PartLogic SKU PL26801461271.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | SLC 500 |
| Part Number | 1746-NI8 |
| UPC | 662072678039 |
| Weight | 1.00 lbs (0.45 kg) |
| Module Type | Analog I/O Module |
| Backplane Current (5 Volts) | 200 milliamps |
| Inputs | 1746-NI4 |
| Backplane Current (24 Volts DC) | 100 milliamps |
| Input signal Category | -20 to +20 mA (or) -10 to +10V dc |
| Bandwidth | 1-75 Hertz |
| Input Filter Frequencies | 1 Hz, 2 Hz, 5 Hz, 10 Hz, 20 Hz, 50 Hz, 75 Hz |
| Update Time | 6 milliseconds |
| Chassis location | Any I/O module slot except slot 0 |
| Resolution | 16 bits |
| Backplane Current | (5 Volts) 200 mA;(24 Volts DC) 100 mA |
| Step Response | 0.75-730 milliseconds |
| Conversion type | Successive approximation, switched capacitor |
| Applications | Combination 120 Volts AC I/O |
| Input Types, Voltage | 10V dc 1-5V dc 0-5V dc 0-10V dc |
| Backplane Power Consumption | 14 Watts Maximum |
| Input Type, Current | 0-20 mA 4-20 mA 20 mA 0-1 mA |
| Input Impedance | 250 Ohms |
| Data Format | Engineering Units Scaled for PID Proportional Counts (-32,768 to +32,767 range), Proportional Counts (User Defined Range, Class 3 only). 1746-NI4 Data Form |
| Cable | 1492-ACABLE*C |
| LED Indicators | 9 green status indicators one for each of 8 channels and one for module status |
| Thermal Dissipation | 3.4 Watts |
| Wire Size | 14 AWG |
| UNSPSC | 32151705 |
| Brand | Allen Bradley |
