Allen Bradley 1746-IG16
The Allen-Bradley 1746-IG16 is a SLC 500 Digital DC TTL Input Module. This Input Module has Sixteen (16) input channels with a voltage range of 4.5-5.5 Volts DC. This module occupies single slot of the SLC 500 chassis.
This Allen Bradley 1746-IG16 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital input > Slc 500 range and is referenced internally as PartLogic SKU PL26805293923.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | SLC 500 |
| Part Number | 1746-IG16 |
| UPC | 662468092722 |
| Weight | 0.50 lbs (0.23 kg) |
| Module Type | Digital DC Input Module |
| Voltage Range | 4.5-5.5 Volts DC Source |
| Inputs | 16 |
| Backplane Current (5 Volts DC) | 140 milliamps |
| Signal delay | 0.25 or 0.5 milliseconds |
| Applications | TTL or BCD inputs |
| I/O Connection | 1746-HT and 1746-HCA |
| Octal Kit | 1746-RL42 |
| Step Response | 100 milliseconds in, 2.5 milliseconds out |
| Removable Terminal Block | 1746-RT25B |
| Watts Per Point | 0.02 |
| Minimum Watts | 0.7 |
| Total Watts | 1 |
| Brand | Allen Bradley |
