Allen Bradley 1746-FIO4V
The Allen-Bradley 1746-FIO4V is a SLC 500 Analog Combination Module. This Analog Combination Module has Two (2) Inputs configurable for 0 to 20 mA or 0 to +10VDC and Two (2) Voltage outputs with nominal range of -10 to +10VDC.
This Allen Bradley 1746-FIO4V is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input > Slc 500 range and is referenced internally as PartLogic SKU PL26933744886.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | SLC 500 |
| Part Number | 1746-FIO4V |
| UPC | 662468523417 |
| Weight | 0.50 lbs (0.23 kg) |
| Inputs | 2 |
| Module Type | Analog Combination Module |
| Outputs | 2 |
| No. of Inputs | Two (2) |
| Backplane Current (5 Volts) | 55 milliamps |
| Input Signal Type | Voltage / Current |
| Backplane Current (24 Volts) | 150 milliamps |
| Input Signal Range | 0…20 mA (nom); 0…30 mA (max) |
| B | 7 kilohertz |
| Output Signal Type | Voltage |
| Output Signal Range | –10 … 10V – 1 LSB (normal) |
| Update Time | 512 microseconds |
| Backplane Current | (5 Volts) 55 milliamps; (24 Volts) 150 milliamps |
| Step Response | 100 milliseconds in, 2.5 milliseconds out |
| Resolution | 12 bits in, 14 bits out |
| Brand | Allen Bradley |
