Allen Bradley 1734-OB8E
The 1734-OB8E is a protected discrete input module that is part of Allen-Bradley’s POINT IO product family. This module features Eight (8) 1 group of 8, non-isolated, sourcing, output channels. Each channel has an operating voltage range of 10-28.8 VDC with maximum output current rating of 1 A per output and 2 A per module. This module has maximum Surge current of 2 A with built-in electronic protection.
This Allen Bradley 1734-OB8E is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Point io range and is referenced internally as PartLogic SKU PL26805308375.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | Point I/O 1734 |
| Part Number | 1734-OB8E |
| Weight | 0.06 lbs (0.03 kg) |
| Power Dissipation | 2.0 W |
| Module Type | Discrete output module |
| Series | POINT I/O |
| No. of outputs | Eight (8), |
| No. of groups | 1 group of 8 |
| Output signal | 10-28.8 VDC |
| Output current per point | 0.041666667 |
| Output current per module | 3 A |
| Surge current | 2 A for 10 ms, repeatable every 3 s |
| Current Draw | 75 mA @5V dc |
| Enclosure type rating | None (open-style) |
| Module Location | 1734-TB or 1734-TBS |
| Outputs | 8 |
| Output Voltage | 24 Volts DC |
| Electronically Protected | Yes |
| POINTBus Current | 75 milliamps |
| Output Current | 3 amps/module |
| Thermal Dissipation | 6.8 BTU/hour |
| Key Switch Position | 1 |
| UPC | 10612598308580 |
| Brand | Allen Bradley |
