Allen Bradley 1734-OB8
The Allen-Bradley 1734-OB8 is a POINT IO module that features Eight (8) Discrete, non-isolated sourcing output channels. It has One (1) group of channels with Eight (8) outputs per channel. It delivers a nominal actuating voltage of 24VDC and compatible with any POINT IO communication adapter for implementing distributed I,O architecture. This module requires 1734-TB or 1734-TBS wiring base assembly.
This Allen Bradley 1734-OB8 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Point io range and is referenced internally as PartLogic SKU PL26801462386.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | Point I/O 1734 |
| Part Number | 1734-OB8 |
| Weight | 0.13 lbs (0.06 kg) |
| Power Dissipation | 2.0 Watt/6.8 BTU/hour |
| POINTBus Current | 75 mA |
| Output Voltage | 24 Volts DC |
| Module Type | Digital DC Sourcing Output |
| Series | POINT I/O |
| No. of outputs | 8; Sourcing output |
| Output Voltage range | 10-28.8VDC |
| Output Current per channel, nom. | 1:00 AM |
| Output Current per module, max. | 3:00 AM |
| Output Signal delay | 0.1 ms |
| Enclosure type rating | None (open-style) |
| Keyswitch position | 1 |
| Module Location | 1734-TB or 1734-TBS wiring base assembly |
| Module Status indicators | 2 green/red, module / network status |
| Input status indicators | 8 yellow, logic side |
| Outputs | 8 |
| Electronically Protected | Yes |
| Output Current | 3 amps/module |
| Thermal Dissipation | 6.8 BTU/hour |
| UPC | 10612598310279 |
| Brand | Allen Bradley |
