Keyence FD-P05
N-Channel PowerTrench MOSFET, 60V, 80A, TO-220AB
This Keyence FD-P05 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Flow sensors > Liquid flow sensors range and is referenced internally as PartLogic SKU PL27022910619.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | TO-220-3 |
| Continuous Drain Current (ID) | 18 A |
| Current Rating | 80 A |
| Drain to Source Breakdown Voltage | 60 V |
| Drain to Source Resistance | 4.3 mΩ |
| Drain to Source Voltage (Vdss) | 60 V |
| Element Configuration | Single |
| Fall Time | 29 ns |
| Gate to Source Voltage (Vgs) | 20 V |
| Height | 20.4 mm |
| Input Capacitance | 3.9 nF |
| Lead Free | Lead Free |
| Length | 10.67 mm |
| Lifecycle Status | Unauthorized. Please upgrade your Nexar subscription to include 'LIFECYCLE'. |
| Manufacturer Lifecycle Status | Unauthorized. Please upgrade your Nexar subscription to include 'LIFECYCLE'. |
| Max Junction Temperature (Tj) | 175 °C |
| Max Operating Temperature | 175 °C |
| Max Power Dissipation | 245 W |
| Min Operating Temperature | -55 °C |
| Mount | Through Hole |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Power Dissipation | 245 W |
| Rds On Max | 5 mΩ |
| REACH SVHC | No |
| Resistance | 5 MΩ |
| Rise Time | 160 ns |
| RoHS | Compliant |
| Threshold Voltage | 4 V |
| Turn-Off Delay Time | 28 ns |
| Turn-On Delay Time | 16 ns |
| Voltage Rating (DC) | 60 V |
| Weight | 1.8 g |
| Width | 4.83 mm |
